Features:

• Windows operation interface, figure button, mouse operation
• 10.4 inche LCD color touch screen, built-in portable computer
• 96-well plate, multiple tests in the single plate
• Plate shaking, speed and time adjustable
• Open system, test item and parameters can be added or modified.
• Large storage for 1000 test item and 1,000,000 results
• External jet printer. Printing comprehensive report, include hosiptal and patient information and test results

Specifications

Microplate types:        96-well plate(U,V,or plat-bottom)

Test mode:             End-point, kinetic, Multi-wave analysis

Light source:            LED > 100,000hours

Measuring system:       8-channel optical system

Wavelength:            405,450,492,630nm, 4 more filters optional.

Wavelength accuracy:    <2nm

Measurement range:     0.000-3.000Abs

Reading range:          0.000-4.000Abs

Well coincidence:        0.015A

Linearity:                r > 0.999

Repeatability:            < 0.3%

Reading speed:          5s single wavelength, 10s double wavelength

QC:                     West guard Multi-rule, automated QC alert.

Self-Checking function:   Self-checking and calibration function.

Printer:                  External jet printer, multi-form patient report.

CPU:                    High-speed CPU

Interface:                RS232 interface, USB

Power supply:            220VAC 15% or 110VAC 15% 50-60Hz 100w

Work environment:        Temp 540; Humi 85%

Size:                    58.5*51*38.5CM

Weight:                  13 KG
