Features:

• 6 detecting wavelengths: 450-492-510-546-578-630nm
• up to 70 test items
• Analytical modes: end-point, absorbance.
• Large LCD. Menu operation, hospital and patient information editing available
• Inner thermal-sensitive printer. English comprehensive report available, including refer range
• Memory for 10000 sample results
• Few reagent needing, low detecting cost.
• Open reagents

Specification

Test project:         70

Wavelength:         450, 492, 510, 546, 578, 630nm

Flow cell:            32uL, quartz glass

Liquid volume:       200-3000uL

Resolution:           0.001Abs (display), 0.0001Abs (calculation)

Carry over:          <1%

Repeatability:        <1%

Printer:             Internal thermal-sensitive printer, 58nm paper width

Display:             240*64 LCD

Data communication: RS-232 serial cable

Power supply:       220VAC15%,50-60Hz 100W

Dimension:          380mm (L)*320mm (W) *150mm (H)

Weight:             7Kg

Usual test list

Alanine Aminotransferase            ALT

Glutamic-oxalacetic transaminase    AST

Alkalinity phosphatase               ALP

Total bilirubin                          TBIL

Direct bilirubin                         DBIL

Total protein                             TP

Albumin                                   ALB

Urea nitrogen                            URE

Inosine anhydride                       CRE

Triglyceride                              TG

Cholesterol                               TCHO

Glucose                                    GLU

Serum potassium                        K

Serum sodium                            Na

Serum chlorine                          CL

Serum calcium                           Ca
